Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam

Cyg Tefa Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam

Brand Name : Green thermal

Model Number : PE Foam

Certification : SGS

Place of Origin : China

MOQ : 500KG

Payment Terms : L/C, T/T, Western Union, MoneyGram

Packaging Details : PE Bags or Customized

Material : LDPE

Density : 25-333kg/m3

Hardness : 20-70

Colour : Customized Colour

Sample : Freely Provide

Feature : Water-proof

Characteristics : Duration

Contact Now

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam

ma  Polietileno Precio Flame Resistant Material Retardant Expanding Crosslinked Xp
e And Ixpe Foam Underlayment
Foam Type: IXPE FOAM / IXLPE FOAM
Property
Standard
Unit
Value
Density
-
Kg/m³
66.70
Tensile Strength
Transverse
ISO-1798
MPa
0.54~0.55

Longitudinal


0.64~0.65
Elongation
Transverse
ISO-1798
%
203.70~232.70

Longitudinal


253.90~283.40
Tearing Strength
Transverse
ISO-8067
Kn/m
3.47~3.68

Longitudinal


4.28~4.34
Operating Temperature Range
Internal
°C
(-40,+80)
Water Absorption % Volume (Maximum)
Internal
%
0.30
Thermal Conductivity
JIS A1412-2
W/mK
0.065
Shore - C
ASTM D2240
°C
40
Flammability
FMVSS302
mm/min
-
Performance
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Heat Insulation

Single foaming structure can reduce the loss of heat between air convection, suitable for making heat preservation pipes and boards.



Waterproof

Closed-cell foam, non-water-absorbing, moisture-proof.



Shock absorption

Soft texture and good resilience enable foam to have a shock absorption effect and play a protective role.Semi-hard quality foams have good rebound capabilities after strong impact.



Sound absorption

Good sound and noise absorption capability.

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Fire retardancy
This product has fire-blocking and smoke-reducing property, when burned, its density is very low and doesn't melt, without any small fire ball left and with the merit of self-extinguishing.

Low conductivity factor
Conductivity of this material is 0.032 w / mk at an average° C. As this product has high heat-releasing ratio, it can get the same
heat-preservation effect at less half thickness of other insulating product under the same condition, saving not only space but also cost.
Product Processing
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Application



Foam tape

IXPE Foam for Photovoltaic tape is a classical cases in our projects. We give a professional solution as followings. IXPE foam with density of 67kg/m3, 1mm, black or white, after gluing, and coated with PE flm on surface, it will be made into the tape with of good tensile property.

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Company Profile



CYG TEFA CO.,LTD

CYG TEFA CO.,LTD is an affiliate of the listed company WOER (Shenzhen: 002130). Established in December 2002, CYG is committed to the research and development, production and sales of cross-linked PE and PP foam materials, and is a national high-tech enterprise. There are two bases in Shenzhen and Huzhou, with more than ten various production lines with an annual production capacity of more than 6,000 tons; The main products are: ESD, XPE, IXPE, IXPP and various composite materials based on XPE, IXPE, IXPP ; Widely used in electronic communications, automotive, air-conditioning refrigeration, construction, sports protective gear, medical supplies and other industries, products are sold to many regions around the world.

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam


Factory Tour
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Granulation workshop

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Extrution line

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Horizontal foaming workshop

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Vertical foaming workshop

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Cutting machine

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Warehouse

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Laboratory

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Laboratory

Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam



Laboratory

Exhibition
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Certificate
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
Wholesale High Quality Cross Linked Polyethylene Foam IXPE Material Sheets Roll closed cell XPE foam
